| Image Sensor: | | | 1/3'' PICADIS |
| Signal System: | | | PAL/NTSC |
| Effective Pixels: | | | 1280 (H) × 960 (V) |
| Min. Illumination: | | | 0.1Lux @ (F1.2,AGC ON),0 Lux with IR 0.14Lux @ (F1.4,AGC ON),0 Lux with IR |
| Shutter Time: | | | 1/25(1/30) s to 1/25,000(1/30,000) s |
| Lens: | | | 2.8-12 mm @ F1.4 Angle of view: 80° - 27.2° |
| Lens Mount: | | | φ14 |
| Adjustment Range: | | | Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360° |
| Day& Night: | | | IR cut filter with auto switch |
| Horizontal Resolution: | | | 720TVL |
| Synchronization: | | | Internal Synchronization |
| Video Output: | | | 1Vp-p Composite Output (75Ω/BNC) |
| S/N Ratio: | | | More than 62 dB |
