| Image Sensor: | | | 1/3” DIS |
| Signal System: | | | PAL/NTSC |
| Effective Pixels: | | | 976(H)×496(V) |
| Min. Illumination: | | | 0.1Lux @ (F1.2,AGC ON),0 Lux with IR 0.14Lux @ (F1.4,AGC ON),0 Lux with IR |
| Shutter Time: | | | 1/25(1/30)s to 1/100,000s |
| Lens: | | | 2.8-12 mm @ F1.4 Angle of view: 80° - 27.2° |
| Lens Mount: | | | φ14 |
| Adjustment Range: | | | Pan: 0 - 355°, Tilt: 0 - 180°, Rotation: 0 - 355° |
| Day& Night: | | | Electronic |
| Horizontal Resolution: | | | 700 TVL |
| Synchronization: | | | Internal Synchronization |
| Video Output: | | | 1Vp-p Composite Output (75Ω/BNC) |
| S/N Ratio: | | | More than 62 dB |
| BLC: | | | On |
